Fiber Optics Distribution Box GP31-2P04A
Overview
LongXing GP31-2P04A optical distribution box is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.
Features
l PC+ABS material used ensures the body strong and light..
l Wet-proof, water-proof, dust-proof, anti-aging
l Easy installations: Ready for wall mount – installation kits provided
l Space saving: Double-layer design for easier installation and maintenances
l Easy installations: Ready for wall mount – installation kits provided.
l Protection level up to IP55
l Cabinet can be installed by the way of wall-mounted or poled-mounted, suitable for both indoor and outdoor uses.
l Distribution panel can be flipped up, feeder cable can be placed in a cup-joint way, easy for maintenance and installation.
l Cable，pigtails，patch cords are running through own path without disturbing each other, cassette type SC adapter or installation, easy maintenance.
Add To Quote List
Add To Compare
Inquiry Now
l Wet-proof, water-proof, dust-proof, anti-aging
l Easy installations: Ready for wall mount – installation kits provided
l Space saving: Double-layer design for easier installation and maintenances
l Easy installations: Ready for wall mount – installation kits provided.
l Protection level up to IP55
l Cabinet can be installed by the way of wall-mounted or poled-mounted, suitable for both indoor and outdoor uses.
l Distribution panel can be flipped up, feeder cable can be placed in a cup-joint way, easy for maintenance and installation.
l Cable，pigtails，patch cords are running through own path without disturbing each other, cassette type SC adapter or installation, easy maintenance.
| Dimensions and Capability | ||
| Adapter Capacity | LC Duplex | SC Simplex |
| 4 | 4 | |
| Dimensions (W*D*H) | 167mm*31mm*102mm | |
| Number of Cable Entrance | Max Diameter 14mm*Q1 | |
| Number of Cable Exit | Up to 4 Drop Cables | |
| Weight | 0.32 KG | |
| Optional Accessories | Adapters, Pigtails, Heat Shrink Tubes | |
| Installation | Wall-Mounted or Pole-Mounting | |
| Operation Conditions | |
| Temperature | -40℃ -- 60℃ |
| Humidity | 93% at 40℃ |
| Air Pressure | 62kPa – 101kPa |
| Shipping Information | |
| Package Contents | Distribution box, 1 unit; Keys for lock, 2 keys Wall mount installation accessories, 1 set |
| Package Dimensions(W*H*D) | 190mm*50mm*120mm |
| Material | Carton box |
| Weight | 0.82 KG |
| Lead Time | 10-15 working days normally |
